XMT-8 17" RTX 4060 I9 14900HX
Processor
14th Gen Intel Core i9-14900HX ( Max Turbo boost up to 5.80 GHz ), 8 P-cores & 16 E-cores / 32 thread, 36MB Smart Cache
Chipset
Intel HM770 Express Chipset
Memory
Supports Dual Channel DDR5
Two 262Pin SODIMM sockets, support for DDR5 up to 4800MHz (Real operation frequency depends on processor)
Expandable up to 64GB, depends on 8GB/16GB/32GB SODIMM module
Display
17.3” QHD (2560x1440) 240Hz, Wide View Angle, 100% DCI-P3, G-Sync Display, Matte Finished
Graphics
Processor NVIDIA Advanced Optimus (Dynamic Display Switching) Technology
Support 5 active displays
Support NVIDIA Surround View via HDMI x1, mini DP x1 and DisplayPort over Type-C
NVIDIA GeForce RTX 4060 Laptop GPU
- 8GB GDDR6 Video RAM
- Microsoft DirectX 12
- NVIDIA CUDA Technology
- Support PCIe Gen4
- Maximum TGP: 140 W (including 25W Dynamic Boost 2.0)
Intel UHD Graphics (Integrated in Core i9-13900HX Processor)
- HDR Support
- Rec. 2020 (Wide Color Gamut)
- Microsoft DirectX 12 compatible
Storage
Two M.2 2280 SSD PCIe Gen 4x4 interface
Audio System
High Definition audio interface
S/PDIF Digital output
Built-in Array Microphone
2 Built-in Speakers
Sound Blaster Studio Pro
Pointing Device
Built-in Click pad with Microsoft PTP multi-gesture and scrolling function
Keyboard
Multi-languages, Single Zone Multi-Color illuminated full size keyboard with numeric pad. (15 colors to select)
I/O Ports
1 HDMI output Port (with HDCP)
1 Mini DisplayPort 1.4 output Port
1 DisplayPort 1.4 over USB 3.2 Gen2 port (Type C)
1 Thunderbolt 4 Port with Power Delivery DC in (Type C)
2 USB 3.2 Gen1 Ports (Type A, 1 x powered USB port, AC/DC)
1 2-in-1 Audio Jack (Microphone / S/PDIF Optical output)
1 2-in-1 Audio Jack (Headphone / Microphone)
1 RJ-45 LAN (10/100/1000/2500Mbps)
Card Reader
Micro SD Card reader
Slots
Three M.2 Card Slots
- 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface
- 2nd for SSD M.2 2280 Card with PCIe Gen 4x4 interface
- 3rd for SSD M.2 2280 Card with PCIe Gen 4x4 interface
Communication
Built-in 2.5 Gigabit Ethernet LAN
Intel Dual Band Wireless Wi-Fi 6E AX211 + Bluetooth, M.2 interface
Security
Security (Kensington Type) Lock Slot
Intel PTT (Platform Trust Technology)
Power System
Embedded 6 cells Polymer battery pack 80WH
Full-Range AC-in 100~240V, 50~60Hz, 280W AC Adapter, DC output 20V, 14A
OS Support
Windows 11 (64-bit)
Certificates
Windows 11 (64-bit) Logo
HDMI Logo
Weight and Dimensions
6.17 lbs. including 80WH battery pack
15.59" (w) x 10.32" (d) x 0.98" (h)
Other Features
Metal top and bottom case
Built-in 2.0M FHD Video Camera with TNR (Temporal Noise Reduction)
FlexiCharger
Virtual Reality ready
Windows Mixed Reality compatible
NVIDIA G-Sync Technology at Dynamic Display Switch mode
Specifications are subject to change without notice
XMT-8 17" RTX 4070 I9 14900HX
Processor
14th Gen Intel Core i9-14900HX ( Max Turbo boost up to 5.80 GHz ), 8 P-cores & 16 E-cores / 32 thread, 36MB Smart Cache
Chipset
Intel HM770 Express Chipset
Memory
Supports Dual Channel DDR5
Two 262Pin SODIMM sockets, support for DDR5 up to 4800MHz (Real operation frequency depends on processor)
Expandable up to 64GB, depends on 8GB/16GB/32GB SODIMM module
Display
17.3” QHD (2560x1440) 240Hz, Wide View Angle, 100% DCI-P3, G-Sync Display, Matte Finished
Graphics
Processor NVIDIA Advanced Optimus (Dynamic Display Switching) Technology
Support 5 active displays
Support NVIDIA Surround View via HDMI x1, mini DP x1 and DisplayPort over Type-C
NVIDIA GeForce RTX 4070 Laptop GPU
- 8GB GDDR6 Video RAM
- Microsoft DirectX 12
- NVIDIA CUDA Technology
- Support PCIe Gen4
- Maximum TGP: 140 W (including 25W Dynamic Boost 2.0)
Intel UHD Graphics (Integrated in Core i9-13900HX Processor)
- HDR Support
- Rec. 2020 (Wide Color Gamut)
- Microsoft DirectX 12 compatible
Storage
Two M.2 2280 SSD PCIe Gen 4x4 interface
Audio System
High Definition audio interface
S/PDIF Digital output
Built-in Array Microphone
2 Built-in Speakers
Sound Blaster Studio Pro
Pointing Device
Built-in Click pad with Microsoft PTP multi-gesture and scrolling function
Keyboard
Multi-languages, Single Zone Multi-Color illuminated full size keyboard with numeric pad. (15 colors to select)
I/O Ports
1 HDMI output Port (with HDCP)
1 Mini DisplayPort 1.4 output Port
1 DisplayPort 1.4 over USB 3.2 Gen2 port (Type C)
1 Thunderbolt 4 Port with Power Delivery DC in (Type C)
2 USB 3.2 Gen1 Ports (Type A, 1 x powered USB port, AC/DC)
1 2-in-1 Audio Jack (Microphone / S/PDIF Optical output)
1 2-in-1 Audio Jack (Headphone / Microphone)
1 RJ-45 LAN (10/100/1000/2500Mbps)
Card Reader
Micro SD Card reader
Slots
Three M.2 Card Slots
- 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface
- 2nd for SSD M.2 2280 Card with PCIe Gen 4x4 interface
- 3rd for SSD M.2 2280 Card with PCIe Gen 4x4 interface
Communication
Built-in 2.5 Gigabit Ethernet LAN
Intel Dual Band Wireless Wi-Fi 6E AX211 + Bluetooth, M.2 interface
Security
Security (Kensington Type) Lock Slot
Intel PTT (Platform Trust Technology)
Power System
Embedded 6 cells Polymer battery pack 80WH
Full-Range AC-in 100~240V, 50~60Hz, 280W AC Adapter, DC output 20V, 14A
OS Support
Windows 11 (64-bit)
Certificates
Windows 11 (64-bit) Logo
HDMI Logo
Weight and Dimensions
6.17 lbs. including 80WH battery pack
15.59" (w) x 10.32" (d) x 0.98" (h)
Other Features
Metal top and bottom case
Built-in 2.0M FHD Video Camera with TNR (Temporal Noise Reduction)
FlexiCharger
Virtual Reality ready
Windows Mixed Reality compatible
NVIDIA G-Sync Technology at Dynamic Display Switch mode
Specifications are subject to change without notice
