UMBRA PRO
- Interchangeable top cover and front panel for either maximum airflow or virtually inaudible operation
- Fan and radiator brackets with integrated fan hub in front and top make installation a breeze
- 3 Silent Wings 4 PWM fans for a virtually inaudible operation and high performance
- Touch-sensitive I/O panel for state-of-the-art operation
- Generous dimensions ensure operation of E-ATX motherboards and radiators up to 420mm
- Well-conceived system for an extremely user-friendly handling
- Flexible motherboard tray for an inverted layout
- Subtle ARGB lighting in the front and the PSU Shroud
General data
Color option Black
Motherboard compatibility E-ATX / XL-ATX / ATX / M-ATX / Mini-ATX
Case size excl. stands (L x W x H), (mm) 604 x 254 x 539
Case size incl. stands (L x W x H), (mm) 604 x 275 x 569
Volume (l) 82.69
PSU form factor ATX PS/2
Net weight (kg) 17.8
Expansion slots 8
Maximum fan installation
Maximum fans 11
Top (mm) 3x 140 / 3x 120
Front (mm) 3x 140 / 3x 120
Side (mm) 3x 120
Rear (mm) 1x 140 / 1x 120
Bottom (mm) 1x 140 / 1x 120
PSU shroud -
Optional radiator installation
Top (mm) 120 / 240 / 360
Front (mm) 120 / 140 / 240 / 280 / 360 / 420
Side (mm) 120 / 240 / 360
Rear (mm) 120 / 140
Bottom (mm) -
PSU compatibility
Maximum dimensions excl. bottom fan (mm) 325
Maximum dimensions incl. bottom fan (mm) 325
Graphics card
HDD cage (in height of graphics card) installed (mm) 350 / 370
HDD cage (in height of graphics card) removed (mm) 495
Maximum PCIe slots with vertical graphics card (pcs.) 8
Drive bay capacity
5.25 bays (pcs.) 1
3.5 slots (scope of delivery) 2
3.5 slots (max.) 7
2.5 slots (scope of delivery) 6
2.5 slots (max.) 16
Cooling
Max.construction height of CPU cooler unit (mm) 190
Airflow channel -
Lighting
LED illumination ✓
LEDs (pcs.) 8 + 16
LED type ARGB - 5V
LEDs synchronizable with controller/motherboard ✓
I/O Panel
USB 3.2 Gen. 2 Type C 1
USB 3.2 Type A 4
USB 2.0 -
HD Audio I/O Mic + Audio
Qi charger / Quick Charging Option (W) 15
Insulation and damping
Top panel insulation mats ✓
Front panel insulation mats ✓
Side panel insulation mats ✓
Anti-vibration decoupled HDD ✓
Anti-vibration decoupled fan ✓
Anti-vibration decoupled PSU ✓
Anti-vibration decoupled motherboard-tray ✓
Scope of delivery
Screw set (Drives/Motherboard) ✓
Additional standoffs (pcs.) 3 (for E-ATX)
SSD bracket for PSU shroud -
LED strips (pcs.) 0
Cable ties (pcs.) 12
Screw box ✓
VGA holder ✓
VGA holder for inverted layout ✓
Mesh Front Panel ✓
ODD Bracket ✓
Fan / Radiator bracket for multi mounting panel ✓
Removeable dust filters
Top -
Front 1
Side -
Bottom 1
Material
Top cover Aluminum
Front panel Aluminum
Side panel Steel
Side panel window Tempered glass
Stands Steel
